SMEC’s HeNB-GW helps to keep the impact of introducing LTE femtocell - even when massively deployed - in the legacy LTE network low, as low as that of small scale addition of macro eNB. This ensures the stability of the LTE core network remains unaffected and the additional investment costs resulting from such deployment are kept to a minimum.
• SMEC’s HeNB-GW delivers both SeGW feature and aggregation feature (for control plane, S1-MME and user plane, S1-U) at a single point, proactively preventing overload at existing MME and S-GW, and also easing potential uncertainty in the legacy LTE network to be caused by tens of thousands of newly deployed femtocells. Also, it helps to bring down the costs for additional installation of MME resulting from the large scale deployment of femtocells (e.g. purchasing additional equipment and license).
• SMEC’s HeNB-GW supports S1 and X2 handover between macro eNB and femtocell, which ensures uninterrupted, reliable call quality, even during switches between the two cells - all just through 4G network (i.e. just through VoLTE) without 2G or 3G.
• SMEC’s HeNB-GW offers X2 service broker feature that provides X2 handover between macro eNB and HeNB without having to modify X2 interface used between the macro eNBs.
1) Traditional HeNB-GW can only support S1 handover, and thus heavy overloads are inevitably passed on to MME during handover. SMEC HeNB GW, however, supports X2 handover where no MME involvement during handover process is needed, drastically reducing overload at MME.
2) It significantly reduces the number of X2 interfaces needed through aggregation of X2 interfaces between macro eNB and femtocells, thereby decreasing network complexity to be caused by X2 interface used in small cell environment.
3) The X2 service broker feature by SMEC, implementable through S1 and X2 interfaces defined in 3GPP Rel. 8., is readily deployable in any LTE system regardless of its release version. Without additional installation of X2 GW nodes defined in R-12 or upgrade of R-12 X2 GW feature license of MME, eNB and HeNB, or of LTE network, X2 handover between macro eNB and HeNB can be readily supported.
|
